Schwank Outdoor Portable or Fixed Mount Patio Heater – parasolSchwank

A heavy-duty commercial-grade outdoor portable propane and fixed mount natural gas portable patio heater. These are low-cost options. The parasol gas heater is built with a durable stainless steel finish and offers an easy to ignite and adjust heat with a turn control.

Portable and fixed-mount commercial patio heaters

These 90” gas patio heaters are built on sturdy 4″ wheels and can easily be moved from one location to another and can be moved to a secure storage location. 32” wide at the base, these patio heaters are available in a portable unit [the base holds a 20/30lb propane tank] and a fixed unit, fueled from your natural gas line.

These Schwank heaters have a stainless steel enclosure and a sleek design to help blend easily into any restaurant design. The portable line is design certified by CSA International for use outdoors in accordance with current ANSI standards.

SKU parasolSchwank Categories , , Tag
parasolSchwank outdoor patio heataers
parasolSchwank
portable outdoor patio heater
portable outdoor patio heater
portable outdoor patio heater
portable outdoor patio heater

Description

Portable or Fixed Mount Patio Heaters – Schwank

  Applications

  • Commercial patios with no roof or nearby walls
Features
  • Heavy-duty commercial grade
  • 38,000 input BTU/hr
  • 90” x 32” heater dimensions
  • Available in single-stage LP/NG
  • Mounting options include fixed mount and portable
  • Control options include on/off switch
  • Attractive stainless-steel finish
  • Easy portability
  • Extra-large propane tank container [20-30lbs], provides longer run times and fewer tank changeovers
  • Perfect for restaurant, hospitality, retail applications
Dimensions and Specifications

          GAS PRESSURE

PORTABLE: FINISH DIMENSIONS INPUT BTU/hr FUEL MIN MAX INLET GAS SUPPLY WEIGHT LBS.
4005-CB Stainless
Steel		 90″ x 32″ 38,000 LP 11″ w.c. 14″ w.c. QCC 20 lb. cylinder 60
GAS PRESSURE
FIXED-MOUNT:  FINISH DIMENSIONS  INPUT BTU/hr FUEL MIN MAX INLET GAS SUPPLY WEIGHT LBS.
4SN5-CB Stainless
Steel		 90″ x 32″  38,000 NG 5″ w.c. 7″ w.c. 1/2″ Piped from
central supply		 60

Parasol 4000 is design certified by CSA International for use outdoors in accordance with current ANSI standards.
Schwank warrants that the heater will operate as designed for wind conditions up to 10 MPH. Please note that adverse wind and weather conditions will reduce the effectiveness of any heating system.
